SIZE |
CENTER of BB to TOP of TT |
EFFECTIVE TT LENGTH |
HT ANGLE |
ST ANGLE |
CHAINSTAY |
WHEELBASE |
FORK RAKE |
BB HEIGHT |
HEADTUBE |
STANDOVER |
STACK |
REACH |
|
48 |
16.34/415 |
20.27/515 |
71 ̊ |
74 ̊ |
16.34/415 |
38.54/979 |
1.97/50 |
10.31/262 |
4.72/120 |
28.03/712 |
20.94/532 |
14.21/361 |
|
51 |
18.19/462 |
20.67/525 |
71.5 ̊ |
74 ̊ |
16.34/415 |
38.82/986 |
1.97/50 |
10.31/262 |
5.51/140 |
29.37/746 |
21.77/553 |
14.37/365 |
|
54 |
18.78/477 |
21.18/538 |
72 ̊ |
73.5 ̊ |
16.34/415 |
38.78/985 |
1.77/45 |
10.31/262 |
6.30/160 |
29.41/747 |
22.64/575 |
14.45/367 |
|
56 |
19.60/498 |
21.85/555 |
72.54 ̊ |
73 ̊ |
16.34/415 |
38.86/987 |
1.69/43 |
10.31/262 |
7.08/180 |
30.90/785 |
23.54/598 |
14.65/372 |
|
58 |
20.23/514 |
22.44/570 |
72.54 ̊ |
72.54 ̊ |
16.34/415 |
39.41/1001 |
1.69/43 |
10.31/262 |
7.87/200 |
31.57/802 |
24.29/617 |
14.96/380 |
|
61 |
20.90/531 |
23.03/585 |
72.54 ̊ |
72.54 ̊ |
16.34/415 |
40.00/1016 |
1.69/43 |
10.31/262 |
8.66/220 |
32.24/819 |
25.04/636 |
15.32/389 |
 |
 |
 |
 |
